mylar tape Manufacturer
Chentao’s Mylar tape has good adhesion and is suitable for applications such as P-coil winding, transformer insulation, and circuit board masking during welding. This product supports customized thickness, is UL/ROHS certified, and offers bulk pricing. Request samples now to get OEM support.
mylar tape Introduction
Engineered for precision electrical insulation and protective applications, Mylar Tape features a durable polyester film backing with a high-tack acrylic adhesive, offering temperature resistance from -40°C to 155°C and excellent dielectric strength (≥6 kV/mm). Ideal for coil winding, transformer insulation, and circuit board masking during soldering, this tape resists moisture, chemicals, and abrasion while maintaining dimensional stability under thermal stress. Its translucent amber or clear design allows visibility of underlying components, and the adhesive leaves no residue upon removal. Compliant with UL 510 and RoHS/REACH standards, it is widely used in electronics manufacturing, automotive motor assembly, and aerospace systems requiring lightweight, reliable insulation.
Technical Specifications
| Item | Specification |
|---|---|
| Thickness | 0.03mm-0.09mm (±0.1mm) |
| Width | 1270mm / Cutting any width |
| Roll Length | 33m / 50m / Custom Length |
| Basic Materials | Polyester film |
| Adhesive Type | Acrylic adhesive |
| Color | White / Black / Yellow / Red / Blue / Green |
| Adhesion to Steel (N/25MM) | 7-14 |
| Temperature Resistance(℃) | -40℃-130℃ |
| Holding Power(Hr) | ＞48 |
| Die-Cutting | Any Shape | Any Size |
Note: All the above data are just for reference, all data might change without notices or updates, please contact our sales team to confirm all details Via Whatsapp or Email.
Optional (OEM / Customized)
- Length
- Width
- Core material and diameter
- Shape(die-cutting)
- Package(Printed / OEM)
